Stolný 6 portový PoE switch AI606 určený pre napájanie PoE zariadení až do vzdialenosti 250m. AI Smart POE Switch, 4x 100Mbps RJ45 port (nastaviteľné POE do 250m), 2x 100Mbps Uplink, 5 pracovných režimov. Napájací zdroj vstavaný priamo v zariadení.
AI606 6-port 100Mbps AI PoE switch (Built-in power)
AI Smart POE Switch
4x 100Mbps RJ45 port (250M POE is available)
2x 100Mbps Uplink
5 working modes:
Standard switching mode: All ports communicate freely;
AI VLAN: Avoid the internet storm and enhance the network ability;
AI Extend: Extend 250M transmission;
AI PoE: Automatic self checking, reboot the device while find it fake dead;
AI QoS，Video data first, more fluent transmission
【Product parameters】
· 4 100Mbps RJ45 ports (support PoE power supply)
· 2 100Mbps uplink port
· Supports 5 working modes: standard switching,AI VLAN,AI Extend,AI PoE,AI QoS mode.
· Supports IEEE802.3af/at，single port output maximum power 30W
· Power supply:60W
【One key switch, five working modes】
· Standard switching mode: All ports communicate freely, suitable for ordinary data transmission environment.
· AI VLAN mode: Separating 1-4 ports from each other, can effectively restrain network storm and improve network performance.
· AI Extend mode: Designed for monitoring application scenarios, 1-8 ports support 250 meters long distance power supply.
· AI QoS mode:Video data first, more fluent transmission.
· AI PoE mode:Automatic self checking, reboot the device while find it fake dead.
【PoE power supply function】
· 4 100M RJ45 ports support PoE power supply, which meets the requirements of PoE power supply in security monitoring, teleconferencing systems, and wireless coverage.
· Support IEEE802.3af/at standard protocol, single port maximum PoE output power is 30W, no need to worry about PoE or non-PoE devices with private standards will be corrupted.
【Stable and smooth transmission】
· With power circuit protection, it can protect the security and stability of the back-end equipment.
· All ports support non-blocking wire-speed forwarding for smoother transmission.
【Green energy conservation】
· Intelligent power supply, the lowest power consumption, to ensure the power consumption of the PD terminal.
· No fan design, energy saving and environmental protection; no noise, reducing the impact on the environment.
· Support port no link power saving function.
【Simple operation】
· Zero configuration characteristic power supply, plug and play, no configuration, simple and convenient.
· The user can easily understand the working state of the equipment through power and port status indicator (Link/Act).
Špecifikácia AI606:
| Parameter | Hodnota |
| Network Port | 4 10/100Mbps PoE RJ45 port (port 1～ port 4) 2 10/100Mbps non-POE RJ45 port(port 5 ~port 6) |
| Transfer Rate | 100Mbps full Duplex, 10 or100Mbps Half Duplex |
| Network protocol and standard | IEEE802.3i, IEEE802.3u, IEEE802.3x, IEEE802.3af, IEEE802.3at |
| Performance | Bandwidth: 2Gbps(no block) Network delay(100 to100Mbps): maximum 20 μs (using 64 byte packet) Frame filtering and transmission rate: 10M port maximum 14,800pps; 100M port maximum 148,800pps |
| LED indicator | Power RESV LINK/ACT |
| POE Pin | 1/2(+)，3/6(-) |
| Power | Max output power single port: 30W Max Power supply: 60W |
| Dimensions | Size (LxWxH):190mm x 40mm x 131mm Weight: 1.5kg |
| Environment | Operating Temperature：0°~40°C Operating Humidity：10%~90%, Non-condensing |
| Safety regulations | CE/ROHS/FCC |
